Jakarta
Bring the texture that comes from nature into your spaces with the comfort of a panel..
Jakarta wall panel reinterprets the textural depth and layered surface character of slate and natural stone claddings through modern panel technology.The panel presents the natural shading, roughness, and undulations of stone with a three-dimensional surface embossing thus creating an aesthetic, durable and practical cladding alternative for both interior spaces and suitable exterior façade applications.
-
GeneralClass of Non-flammability: Euroclass TS EN 13501-1 EU" norms, "Class A2 s1 d0 - Non-combustible"Density: "1.46 gr/cm³" according to "TS EN ISO 1183-1" normsTemperature Resistance Limit: "No deterioration at 800 °C" according to "ASTM E1069" normsBarcol Hardness: "52" according to "TS EN 59" normsImpact resistance -Ball Method: "No crackages" according to "DIN ISO 4586 T12" normsImpact Resistance - with Charpy Device: "30 kj/m2" according to "TS EN ISO 179-1" normsSound Insulation: "40 dB" according to "TS EN ISO 140-3" normsFrost Resistance: "No deterioration" according to "ASTM C 666" norms
-
Technical DescriptionThe Jakarta wall panel is an advanced composite cladding system developed to reproduce the surface character of natural stone. The surface topography of the panel transfers the layered structure of stone blocks, the distribution of surface roughness, micro-porosities, and light–shadow depths onto the panel through high-resolution molding. This reflects, one-to-one, the volume and texture sensation seen in real stone claddings when interacting with light.
The load-bearing body of the panel is created by the combination of a fiber-reinforced upper layer and a mineral-enhanced dense lower layer.This composite structure ensures that the panel is both lightweight and highly rigid. Fiber reinforcement guarantees that the panel maintains its form under mechanical stresses such as bending, twisting, or impact, and keeps the surface stable even across large areas. Risks such as surface cracking, breakage, or layer separation under impact, pressure, or surface loads are minimized.
The surface coating of the panel is stabilized with protective components against water, moisture, rain, UV radiation, freeze–thaw cycles, and external environmental effects.Therefore, besides being an interior wall-cladding option, the panel also provides long-lasting use on exterior façades or semi-open spaces with proper detailing.Because the surface pore structure is designed in a controlled manner, dirt retention is reduced and maintenance needs are minimized.
Thanks to its composite infrastructure, Jakarta can be cut, drilled and shaped according to architectural details; this allows electrical socket & lighting line transitions, infrastructure channels or special architectural details to be easily integrated into the panel.Using mechanical fastening (screw + anchor) as the recommended installation method ensures that the panel sits fully on the surface, preserves surface integrity and guarantees long-term stability.
The product has an EPD (Environmental Product Declaration) certificate, which provides an important advantage for sustainability- and environmental-responsibility-oriented projects. This certification enables projects using the Jakarta Slate panel to gain points in LEED, BREEAM, WELL and similar green building rating systems particularly in criteria related to environmental performance and sustainability. In this respect, Jakarta Slate is not only an aesthetic and structural solution but also a cladding option that offers environmental responsibility.
In conclusion, Jakarta wall panel is a stone-cladding panel that combines the aesthetics of natural stone with modern panel technology, high durability, workability and sustainability advantages; it is a long-lasting, aesthetic and environmentally compliant stone cladding panel suitable for both interior and exterior applications. -
FormatsPanel Size: 238 cm × 120 cm [h] (±1%)Panel Thickness: ~ 12 – 14 mmTexture Depth: ~ 14 – 16 mmWeight: ~ 5 – 6 kg/m²
-
Usage:InteriorExterior
